TECHNICAL DATA

Load capacity  41 Tn (90390 lb)

Minimum height  178 mm (7.01 in)

Hydraulic stroke 306 mm (12.05 in)

Mechanical extension 72 mm (2.83 in)

Maximum height (with mech. ext.)  556 mm (21.89 in)

Baseplate width   182 mm (7.17 in)

Total weight 119 Kg (262 lb)

Double independent hand pump for high and low pressure, with

safety valve.

Ram set salt bath nitrided and polished.

Design and Factory Safety overload test in accordance with

EN-12312-19.

Pneumatic pump of high flow. Max. inlet pressure 150 PSI.

Autoretract system with the pneumatic line.

Rain hat (option).

Skydrol resistant paint.

Towbar & all functional parts protected against weather and

rough operation.
