Antenna Options Available Rod: 110-338, Whip: 110-773

Operating Frequencies:406 MHz, 121.5 MHz +/- 5 KHz

Ouput Power:406 MHz: 5 W (440 ms/ 50 sec) for 24 hours @ -20°C to +55°C, 121.5 MHz: 100 mW minimum for 50 hours @ -20°C to +55°C

Output Connector:BNC Female (406 MHz & 121.5)

Activation: Automatic by 4.5 feet per second (2.3 G) Primary G-Switch or Manual Activation

Battery: 6-year Lithium (LiMnO2, solid cathode), Replacement Battery Part No. 455-0012

Temperature Certified to: Operating: -20°C to +55°C, Storage: -55°C to +85°C

Self Test: G-Switch Enabled, 406 MHz Power, Antenna/Coax Connection, Low Battery

Remote Control: ON/ARM

Weights (with tray): 2.05 lbs (933 g)

Measurements: ELT Transmitter with mounting hardware installed: 6.59” (167 mm) L

uage:Z？A>？P？0？？nts 6.59” (167 mm)L x 2.86”
