AT-602
Small Fixed Aircraft
- Model : AT-602
- Part Number :
Product Details
High Production Efficiency.
The AT-602 is designed for operators needing more than 500 gallons, but less than the 800-gallon AT-802. It takes just one load to spray a 125-acre circle at 5 gallons per acre. Ferry times are shortened by its powerful PT6A-60AG engine. The AT-602 is the perfect match of hopper capacity to engine performance. The 602 lets operators streamline from a multi-plane to a single-plane operation with plenty of productivity, reduced overhead and better profit margins.
SPECIFICATIONS
| Engine Type: | P&W PT6A-60AG |
| Engine S.H.P.: | 1,050 @ 1,700 RPM |
| Propeller: | Hartzell HC-B5MP-3C/M10876ANS |
| Take-Off Weight: | 12,500 lbs. (5 670 kg) |
| Landing Weight: | 12,000 lbs. (5 443 kg) |
| Empty Wt. w/Spray Equip.: | 5,829 lbs. (2 644 kg) |
| Useful Load: | 6,671 lbs. (3 026 kg) |
| Hopper Capacity: | 630 U.S. gal. (2 385 L) |
| Fuel Capacity: | 216 U.S. gal. (817 L) |
| Wing Span: | 56 ft. (17,06 m) |
| Wing Area: | 336 sq. ft. (31,24 m2) |
| Main Wheel Size: | 29.00 x 11-10 |
| Tail Wheel Size: | 17.5 x 6.25-6 |
PERFORMANCE
| Cruise Speed: | 182 mph (293 kph) at 8,000 ft. |
| Working Speed (Typical): | 145 mph (233 kph) |
| Range, Economy Cruise at 8,000 ft.: | 600 mi. (966 km) |
| Stall Speed, Flaps Up: | 99 mph (159 kph) at 12,500 lbs (5 670 kg) |
| Stall Speed, Flaps Down: | 82 mph (132 kph) at 12,500 lbs (5 670 kg) |
| Stall Speed as Usually Landed: | 60 mph (97 kph) |
| Rate of Climb: | 650 fpm (198 mpm) at 12,500 lbs (5 670 kg) |
| Take-Off Distance: | 1,830 ft (558 m) at 12,500 lbs (5 670 kg) |
